High-Speed Paper Cup Forming Machine

High Speed Horizontal Paper Cup Machine 3 in 1

Introduction:
Zhejiang Ruida Machinery’s latest innovation achieves a production speed of 230 cups per minute—15% faster than conventional models—while maintaining ultra-low energy consumption. It features a full servo-driven system with 0.02mm positioning accuracy, real-time PLC monitoring of 23 critical parameters, and instant self-correction for continuous operation.
Important parameters:

Speed:220-260pcs/min

Cup Size: 6-22oz

Request an inquiry
More than 360° rolled edges
Tightly folded bottom
Fine pattern printing
Product Application
Product Description
Main Technical Parameters
Detailed presentation
Related Products
Product Description
Main Technical Parameters
Detailed presentation
Related Products
Product Description

Precision Manufacturing at 230 Cups/Minute

Industry-Leading Performance

The next-generation RD-230A horizontal paper cup machine delivers unprecedented production efficiency (260 cups/min) with PLC+servo motion control and full photoelectric monitoring - ensuring your packaging operation stays ahead of demand.



Smart Production Intelligence

1. Auto-fault detection with instant shutdown (reduces material waste by up to 30%)
2. AI-powered vision system for real-time defect detection (>99% quality rate)
3. Digital temperature control (±1℃ accuracy for perfect sealing)
4. Servo-driven precise feeding (continuous operation with <0.5mm deviation)



Unmatched Flexibility

* Quick-change mold system adapts to multiple market needs (6-22oz sizes)
* Factory Automation Ready
* Integrated counting/stacking module enables direct connection to packaging lines, cutting labor costs by 40% compared to manual handling.



Why Global Brands Choose Ruida:

* more than 20 Years OEM Experience

* CE Certified Manufacturing

* 24/7 Remote Technical Support









Main Technical Parameters

Model

RD-230A

Forming size

Top Diameter:  60-100mm

Bottom Diameter:   40-75mm

Height:        60-180mm

Paper Specifications

170-350g/m²

Paper Material

Single and double PE/PLA/Non plastic coated paper

Speed

220-260pcs/min

Power supply

380V 50Hz

General Power

55kow(real working power 26kw)

Air source

0.6m³/min

Weight

7500Kg

Packing specifications

3300*2140*2350mm
Product details display
Cup body sealing advantages
The lap joint is keeping vertical mechanical pressed and formed during the four process which includes: cup clamp—bottom hot air 1—bottom hot air 2—bottom folding. The design had greatly Improved energy efficiency and reduced energy consumption.
Constant pressure knurling
Knurling bearings have a longer lifespan (up to one year or more). There are repair slots on the embossing outer mold (customized according to the thickness of the paper) to make the pressure of the embossing wheel on the bottom embossing more uniform (constant tension), and the bottom bonding and sealing are better, greatly reducing the probability of leakage caused by poor embossing at the bottom.
Control system advantages
RD-230A uses servo precision control for the front paper feeding station,and the forming station uses dual indexing curved mechanical cams to control 11independent assemblies,with high accuracy and good stability!
